Product Overview

The Supermicro 1U hot-swap dual node 1U TwinPro¿ family of SuperServer® systems offers the very best solution for customers who need high compute density with redundancy for high availability applications. With dual DP compute nodes accessing up to 2TB of memory, the system provides the highest levels of performance in a 1U form factor. The 1U TwinPro also offers improved serviceability with compute nodes that are cableless and easy for technical staff to access. These benefits are enhanced with the most advanced networking and storage features, including 1/10/25/50/100G Ethernet or 56G InfiniBand, and 4x 2.5" SAS 3.0 (12Gbps) or SATA 3.0 drive bays per node. Availability is significantly enhanced with redundant high-efficiency Titanium Level compact power supplies. The 1U TwinPro systems offer an impressive set of features packed into a 1U form factor, including dual hot-swap nodes and redundant 1000W Titanium Level (96%+) compact power supplies, each node supporting dual Intel® Xeon® Scalable processors (up to 56 cores, up to 165W TDP per processor), up to 2TB ECC DDR4-2666MHz in 16 DIMM slots, 4 hot-swap 2.5" HDD/SSD drive bays, 2 PCI-E 3.0 x16 Low-profile slots, SIOM slot for flexible networking options (1G, 10G, 25G, 50G, 100G), 2 SATA/NVMe M.2 slots with optional adapter, 2 SuperDOM ports, 2 USB 3.0 ports, IPMI 2.0 with dedicated LAN port & KVM; 4-pin PWM Fan Speed Control; and Thermal and Voltage Monitoring. Optimized for high-end Enterprise, HA storage head node, security appliance, the Supermicro 1U TwinPro family is designed for best performance and density, with highest availability, for continuous operation at maximum capacity running the latest high-capacity, mission critical workloads. The resulting benefit is best TCO for customers seeking the greatest competitive advantage from their data center resources.

Specifications
