Product Overview

Mfr Part Number: H270-F4G-SI Motherboard: MH70-HD0 Processor Per Node: Dual LGA2011-3 Supports Intel Xeon E5-2600 V3/V4 processors Chipset: Intel C612 Memory Per Node: 16x DDR4-2400/ 2133/ 1866/ 1600 MHz DIMM Slots, Quad Channel Support RDIMM Modules Up to 32GB Support LRDIMM Modules Up to 64GB Support 3DS LRDIMM modules up to 128GB Slots Per Node: 1x Half-length low-profile slot with PCI-Express 3.0 x16 Connector, 1x Mezzanine PCI-Express 3.0 x8 Connector SATA Per Node: 6x SATA3 Ports, Support RAID 0, 1, 5, 10 Video Per Node: Integrated Aspeed AST2400 Graphics LAN Per Node: 2x Intel 82599ES 10GbE with QSFP+ LAN Ports; 1x 10/100/1000 management port Drive Bays Per Node: 4x 2.5" hot-swappable HDD/SSD bays Ports Per Node: 4x USB 3.0 Ports (2 rear, 2 front), 2x VGA Ports (1 rear, 1 front), 1x Serial Port, 1x RJ45 MLAN Port Form Factor: 2U Rackmount Power Supply: 2x 1600W 80 PLUS Platinum Certified Power Supply System Cooling: 16x (40x40x56mm) Fans (23000rpm) Dimensions (WxDxH): 447.0 x 780.0 x 87.2 mm Weight: 38.0 kg
