Product Overview
Key Features Intel® Xeon® processor E3-1585L v5, Single socket FCBGA 1440, 4-Core, 8 Threads, 45W Intel® C236 chipset Up to 64GB ECC Unbuffered SO-DIMM, DDR4 2133MHz; 4 DIMM slots Support Intel® Iris Pro Graphics P580 (GT4e) , for VHD and Quick Sync Video Expansion slots: 1 PCI-E 3.0 x8 (in x16), 1 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8) 6 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10 2 SuperDOM with built-in power 5 USB 3.0 (2 rear, 1 Type A, 2 internal) M.2 NGFF connector
Specifications
Product SKUs
SuperServer 5019S-M (Black)
Motherboard
Super X11SSH-F
CPU
Single Socket H4 (LGA 1151) supports: Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen Core¿ i3 CPU TDP up to 80W
Memory Capacity
4x 288-pin DDR4 DIMM slots Up to 64GB DDR4 ECC UDIMM
Memory Type
2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (UDIMM) gold-plated DIMMs
DIMM Sizes
16GB, 8GB, 4GB
Chipset
Intel® C236 chipset
SATA
SATA3 (6Gbps) via C236 controller RAID 0, 1, 5, 10 support
IPMI
Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC
Network Controllers
Dual Intel® I210-AT Gigabit Ethernet LAN ports Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Power Supply
350W AC power supply w/ PFC
System BIOS
BIOS Type: 8MB SPI Flash EEPROM with AMI BIOS BIOS Features: DMI 2.3 PCI 2.3 ACPI 1.0 / 2.0 USB Keyboard
PC Health Monitoring
Voltage: Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages. FAN: Total of 4 fan headers supporting up to 4 fans 4 fans with tachometer status monitoring Status monitor for speed control Status monitor for on/off con
Operating Environment
RoHS Compliant Environmental Spec.Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity:8% to 90% (non-condensing) Non-operating Relative Humidity
